Five axis Metal Laser Additive Composite Manufacturing System

Brief Description

Product features:
1. Organic combination of additive manufacturing and subtractive manufacturing;
2. Can perform powder coating additive, milling, grinding and polishing composite processing;
3. Equipped with a knife magazine, automatic tool changing a

Categories Metal powder energy deposition equipment (LMD)

Equipment parameters

Working range	Φ400mm x 350mm
Travel X-axis	600mm
Travel Y-axis	500mm
Travel Z-axis	650mm
X&Y&Z axis positioning accuracy	0.01mm
X&Y&Z axis Repeatability positioning accuracy	±0.005mm
Spindle speed	18000rpm
Number of cutting tools	20 pieces (16 pieces optional)
Maximum drilling diameter	Φ16mm
Maximum boring diameter	Φ60mm
Workbench size	Φ500mm
Workbench load-bearing capacity	500kg(0°)、300kg(90°)
Control system	Siemens 840D
Machine weight	7000kg
Overall dimensions	3500mm x 2500mm x 3600mm
